Telescopic Hydraulic Cylinder For Concrete Pump Truck
Telescopic Hydraulic Cylinder For Concrete Pump Truck
The following is telescopic hydraulic cylinder for concrete pump truck. Toleng is a leading manufacturer of high quality hydraulic cylinders in China, dedicated to providing excellent solutions to customers worldwide. Our products cover a wide range of applications, providing our customers with high performance. Each product can be customized to meet specific requirements to ensure that it meets the needs of various application scenarios.
Send Inquiry
Product Description
Toleng has a great range of hydraulic cylinders, which can be used in the construction, agriculture, sanitation industry, and so on. At Toleng, each cylinder is carefully made to meet strict industry standards, guaranteeing reliable performance and exceptional durability.
This telescopic hydraulic cylinder for concrete pump truck has multiple stages that can achieve different stroke lengths. This design makes it ideal for applications where extended reach and flexibility are essential. This telescopic hydraulic cylinder for concrete pump truck is versatile and compatible with various concrete pump models, making it suitable for a wide range of lifting tasks.
This telescopic hydraulic cylinder for concrete pump truck has multiple stages that can achieve different stroke lengths. This design makes it ideal for applications where extended reach and flexibility are essential. This telescopic hydraulic cylinder for concrete pump truck is versatile and compatible with various concrete pump models, making it suitable for a wide range of lifting tasks.
Application
-Boom Cylinder
-Slide Cylinder
-Concrete Cylinder
-Transmitting Cylinder
-Swing Cylinder
-Slide Cylinder
-Concrete Cylinder
-Transmitting Cylinder
-Swing Cylinder
Technical Parameter
| PART No. | STROKE | A | B | C | D | E | F | G | H | L | PORT |
WEIGHT [Lbs] |
VOLUME [Gal.] |
| 7 TONS INVERSE | |||||||||||||
| WT07078 | 78" | 35.5" | 3.75" | 2" | 1.063" | 3.0" | 1.25" | 6.5" | 1.25" | 7" |
SAE #8 (3/4-16UNF) |
68 | 1.6 |
| WT07090 | 90" | 39.5" | 3.75" | 2" | 1.063" | 3.0" | 1.25" | 6.5" | 1.25" | 7" | 75 | 1.8 | |
| WT07108 | 108" | 45" | 3.75" | 2" | 1.063" | 3.0" | 1.25" | 6.5" | 1.25" | 7" | 101 | 2.2 | |
| 12 TONS INVERSE | |||||||||||||
| WT12078 | 78" | 34.75" | 4.4” | 2 | 1.063" | 3.0" | 1.5” | 7.5" | 1.5" | 7" |
SAE#8 (3/4-16UNF) |
106 | 2.5 |
| WT12090 | 90" | 38.7" | 4.4" | 2 | 1.063" | 3.0" | 1.5" | 7.5" | 1.5" | 7” | 107 | 2.8 | |
| WT12108 | 108" | 44.75" | 4.4” | 2" | 1.063" | 3.0" | 1.5" | 7.5" | 1.5" | 7" | 132 | 3.4 | |
| WT12120 | 120" | 48.75" | 4.4" | 2" | 1.063" | 3.0" | 1.5" | 7.5" | 1.5" | 7" | 143 | 3.8 | |
| WT12144 | 144" | 56.78” | 4.4” | 2" | 1.063" | 2.25" | 1.5" | 7.5" | 1.5" | 7” | 166 | 4.6 | |
Details
Hot Tags: Telescopic Hydraulic Cylinder For Concrete Pump Truck
